Scan Engine
Intel® RealSense™ Camera
Scan Volume
Maximum Scan Volume (WxDXH)
Head Mode :15.75 x 9.84 x 15.75 inch / 40 x 25 x 40 cm
Object Mode :23.6 x 23.6 x 11.8 inch / 60 x 60 x 30 cm
Minimum Scan Volume (WxDXH)
:1.97 x 1.97 x 1.97 inch / 5 x 5 x 5 cm
Scan Resolution : 1.5mm
Depth Image Size :640 x 480 @ 30 FPS
Color Image Size :640 x 480 @ 30 FPS
Operating Range : 3.93 – 27.55 inch (10 – 70 cm)
Data Interface : USB 3.0 or above
Dimension : 1.61 x 6.18 x 2.4 inch (41 x 157 x 61 mm)
Net Weight: 0.52 lbs (238g)
Software
Output File Types : XYZscan/.stl, .obj
Operating System : Windows 8.1 and above (32-bit and 64-bit)
Microsoft .NET Framework 4.0 above
Hardware
Minimum Hardware Requirement : 4th Generation Intel® Core™ i5 Process (PC)
4G RAM Basic (8G RAM Recommended)
Official Website : http://global.xyzprinting.com/global_zh_hk/Product/3D-Scanner
